MIC Channel

4 Mono

Channel EQ

2 Band

AUX

1

Return

1

Effects 16 DSP

24 Bit

Main EQ

5 Band

Main Out

1

Phantom Power

48V DC

USB Player

Optional

Maximum Output Power of power amplifier, 1 kHz, THD=1%:
into 4 Ohms = 34v = 300 W
into 8 Ohms = 34v = 150 W
RMS Output Power of power amplifier, 1 kHz, THD=1%:
into 4 Ohms = 21v =  2 x 110 W
into 8 Ohms = 24v =  2 x   70 W

TECHNICAL SPECIFICATIONS

Maximum levels

Mic Input 30dBu

Line Input 21dBu

All other lnput 22 dBu

Mixer Rated Output

Main outs +4dBu

All other outs +4 dBu

Maximum output 20 dBu

Frequency response

Mic lnput to main output +0,-1 dB,<20Hz to 40kHz

+0,-3 dB,<20Hz to 60kHz

Connection lmpedances

Mic Inputs >200 ohms

Line Inpus >10K ohms

Outputs:>100 ohms

 EQ(each band)±15dB

Mono channel EQ

High  12KHz

Low 80Hz

Размер: 300 х 320 х 145 мм

Тегло: 6 кг
